| Model: | WB-SPDU-2000 |
| Place of Origin: | Zhejiang,China (Mainland) |
| Brand Name: | WEBITELECOMMS |
| Material: | SPCC shell |
| Installation: | Horizontal installation |
| Product series: | Remotely control&monitor |
| Main cable: | 3G * 6mm² * 3Mtr |
| Control: | Each outlet control; |
| Monitoring to outlet current; |
| Quantity: | |
|---|---|
WB-SPDU-2000-14
Webit Intelligent PDU is a network-grade power distribution unit , designed for precision control in modern DATA CETNERS & SERVER ROOMS.
Moving beyond basic PDU, smart PDU empowers IT adminstrators to manage rack power remotely with outlet-level granularity. It integrates real-time electrical metering, envionmental monitoring, alarm system into a compact 1U device. Transforming power from a utility into a manageable and intelligent asset.
WebiT Smart PDU contains two series - WB-SPDU2000 (Standard Size) & WB-SPDU5000 (Non-standard size).
And each series include 4 models : A, B, C and D which can meet mostly of user requirements for varies enviroment.
WebiTelecomms SPDU are widely applied to 19" standard and non-standard server rack or network cabinet.
A level - Each outlet monitored and controlled
B level - Group circuit monitored and controlled
C level - Each outlet monitored
D level - Group circuit monitored
Core Intelligent Features & Benefits
Individual Outlet Control & Sequencing
Power each connected device on or off remotely via a web browser or SNMP commands. Schedule reboots, implement power-on/power-off delays to protect equipment, and manage energy consumption with precision. This eliminates the need for physical access to the rack for routine power cycling.
Real-Time Power Monitoring & Analytics
Monitor vital electrical parameters at both the PDU level and per individual outlet. View real-time data for voltage, current (A), power (KW), and energy consumption (KWH). This visibility is crucial for capacity planning, preventing circuit overloads, and optimizing power usage effectiveness (PUE).
Comprehensive Environmental & Security Sensing
The PDU can integrate with optional sensors to monitor rack health. Keep track of temperature and humidity to prevent thermal damage, and receive instant alerts for critical events like smoke detection, water leakage, or unauthorized cabinet door access.
Proactive Multi-Channel Alerting
Configure custom thresholds for electrical and environmental parameters. The system provides immediate notification through multiple channels—including on-unit buzzer, email —when limits are exceeded, enabling rapid response to potential issues before they cause downtime.
Enterprise Management & Integration
With support for SNMP protocol, this PDU seamlessly integrates into existing network management systems like StruxureWare Data Center Expert. Its firmware is also network-upgradeable, ensuring your investment remains up-to-date with new features without hardware replacement.
Communication Function
User can by means of the remote device via the WEB,SNMP to view,function configuration parameters and power control
Quickly and easily upgrade firmware via network download for future preduct enhancement liminates the need to replace products when new features are released
Features
◆ LED indicator for each outlet
◆ Pothook installation
◆ Each outlet Monitor&Control
◆ Current & Volt metered
◆ Flash Upgradeable
◆ Power on/off Delays protection
◆ Alarm Thresholds
◆ Network Management Capabilities
◆ Integrates with StruxureWare Data Center Expert
Data
◆ Nominal Output Voltage:100V , 200V , 208V , 230V
◆ Output Maximum Total Current Draw16A
◆ Input Maximum Input Current:20 A
◆ Acceptable Input Voltage:100-240 VAC
◆ Operating Environment:-5 - 45 °C
◆ Operating Relative Humidity:5 - 95 %
◆ Storage Temperature:-25 - 65 °C
◆ Storage Relative Humidity:5 - 95 %
Ready to upgrade your rack power strategy? Contact us today for detailed datasheets, volume pricing, and configuration advice tailored to your specific data center needs.
Contact WEBITELECOMMS:
Add: NO.28 Jiangnan Rd. Hi-tech Zone, Ningbo, China
Tel: +86-574-27887831
WhatsApp: +86-15267858415
